Explore our industrial-grade OEM/ODM product lineup, fabricated to meet North American NAFS, Australian AS2047 cyclonic, and European CE standards. Every door system undergoes digital coordinate dimension control and rigorous dry-hung testing prior to export packing.
In modern commercial architecture and high-end residential engineering, an aluminum glass door is not merely a partition; it is an active building envelope barrier responsible for structural integrity, cyclonic wind deflection, building thermodynamic insulation, and long-term acoustic isolation.
We source primary A00-grade virgin aluminum billets to extrude profiles according to EN 755 and ASTM B221 specifications. Alloy selections range from standard architectural 6063-T5/T6 (tensile strength ≥ 215 MPa) to high-load marine-grade 6061-T6 or 6082-T6 for severe seismic and high-rise exposure zones.
Eliminating thermal bridging across fenestration systems requires advanced composite engineering. We mechanically crimp German-engineered PA66GF25 (polyamide reinforced with 25% glass fiber) thermal struts between interior and exterior aluminum extrusions, yielding superior thermal expansion coefficient stability matching the metal substrate.
Glazing units are processed in dust-free cleanrooms utilizing automated CNC edge-seaming, convection tempering furnaces, and dual-seal silicone structural glazing lines. Options cover double- and triple-glazed IGUs with soft-coat Low-E (solar control), argon filling (90%+), and acoustic laminated setups.
| System Series | Extrusion Profile Alloy | Thermal Barrier Configuration | Glazing Pocket Depth | Standard Acoustic Rating | Certified Wind Load (Pa) |
|---|---|---|---|---|---|
| RG93.6 Heavy Sliding | 6063-T6 (2.0–2.5mm) | 34mm Multicavity PA66GF25 | 32mm – 42mm Double/Triple IGU | STC 41 dB | 4500 Pa (AS2047 N6 / ASTM E330) |
| AOSTTER Balcony Bifold | 6063-T5 (2.2mm) | 24mm Technoform Polyamide | 28mm – 36mm Low-E Tempered | STC 43 dB | 3800 Pa (Serviceability Limit) |
| Architectural Large Pivot | 6061-T6 / 6063-T6 (3.0mm) | Continuous EPDM + Composite Core | 38mm – 50mm SGP Laminated | STC 45 dB | 5000 Pa (Severe Coastal Rating) |
| Minimalist Hidden Hinge | 6063-T6 Structural Grade | Flush Monolithic / Thermal Option | 12mm – 24mm Acoustic Glass | STC 39 dB | 2800 Pa (Interior / Sheltered Exterior) |
| Commercial Overhead Garage | 6063-T5 Heavy Channel | Integrated Weather Seal Track | 16mm – 22mm Frosted / Clear Double | STC 34 dB | 3200 Pa (High-Exposure Commercial) |
Global architectural procurement is shifting towards carbon transparency, extreme climatic resilience, and deep building management integration. B2B importers and commercial contractors must align their supply chains with the following emerging procurement vectors:
Institutional developers across Europe, North America, and Australasia now mandate Environmental Product Declarations (EPD). Tier-1 procurement favors secondary billet casting with up to 75% recycled scrap content and primary smelters powered by renewable hydroelectric energy, reducing embodied carbon to ≤ 4.0 kg CO₂e per kg of fabricated aluminium.
Architects demand panoramic views with sightlines as thin as 20mm, without sacrificing structural load bearing. This drives procurement towards monolithic floor-to-ceiling sliding systems equipped with fully recessed frames, stainless steel drainage troughs, and in-wall automated electromagnetic drive modules with soft-start kinematics.
The convergence of building automation systems (BMS) with high-performance doors is accelerating. Smart fenestration procurement now encompasses electrochromic switchable glass, integrated motorization, fingerprint and 3D facial recognition handles, and wireless contact sensors compatible with KNX, Zigbee, and Matter standards.
How cutting-edge robotics, 5-axis CNC machining centers, and nanotech surface coatings elevate Chinese fenestration engineering to match and exceed European heritage brands.
Traditional manually-cut miter joints are susceptible to moisture seepage and deflection. Modern fabrication utilizes high-speed continuous CNC centers where lock boxes, hinge mortises, drainage weeps, and corner-crimping keys are routed in a single clamping setup, guaranteeing dimensional tolerances within ±0.2mm.
For coastal villas in Lagos, Dubai, Sydney, or Miami, atmospheric salt spray rapidly pits lower-tier finishes. We utilize 3-coat/2-bake Kynar 500 PVDF fluorocarbon coatings and Qualicoat Seaside certified powder coatings capable of exceeding 4,000 hours of continuous neutral salt spray (NSS) testing.
Air permeability class 4 and watertightness class E1050 rely on elastic memory. Rather than using cheap PVC strips that shrink under UV radiation, our doors incorporate automotive-grade vulcanized EPDM rubber gaskets with co-extruded foam cores and pre-molded vulcanized 90-degree corner joints.
Operating from our 180,000 m² smart production campus in Foshan, Guangdong—the world capital of aluminium extrusion—our enterprise combines massive volume throughput with artisanal bespoke customization for prestigious developers globally.
Consolidate exterior entry pivot doors, bifold walls, sliding courtyard doors, acoustic office partitions, and automated glass garage doors into single 40ft HQ containers, eliminating inter-supplier mismatches.
Our 40+ project engineers transform your architectural elevations into fully annotated shop drawings, wind load deflection calculations, glass stress analyses, and 3D BIM Revit objects with 48-hour turnarounds.
Every custom door undergoes 100% full dry-hung assembly, diagonal squareness verification, locking gear calibration, and water spray testing in our inspection hangar before dismantling and export packing.
To eliminate transit damage over 60-day ocean freight routes, products are protected with protective film, foam wrapping, corner guards, and crated inside fumigated solid plywood cases with desiccant packs.
Clear, direct answers regarding engineering approvals, minimum order quantities, compliance documentation, custom extrusions, and overseas site support.
Standard custom architectural orders require 25 to 35 business days from final sign-off of CAD shop drawings. For projects requiring custom profile die extrusion tooling, add 10 to 14 days for die creation and sample extrusion metallurgical testing. Expedited fast-track protocols are available for time-sensitive commercial projects.
Yes. We engineer systems compliant with Australian AS2047 (N6 cyclonic ratings up to 4500 Pa), Florida Building Code (Miami-Dade NOA missile impact testing), and North American ASTM E330 / NAFS standards. Structural reinforcing steel fins, thick-wall 6061-T6 profiles, and SentryGlas (SGP) laminated interlayers are specified to resist high-velocity wind zones.
We support scalable procurement: for custom luxury villas and bespoke private estates, our MOQ is 1 set. For commercial developments, wholesale importers, and containerized orders, we provide graduated tier discounts based on total square meters (m²) and full container load (FCL) packing efficiency.
For coastal locations within 1 km of seawater (e.g., Lagos, Durban, Mombasa, Caribbean islands, Gold Coast), we specify Class I Anodizing (≥ 25 microns) or PVDF (Fluorocarbon) 3-coat systems compliant with AAMA 2605. In addition, all internal screws, pivot bearings, roller tracks, and mortise cases are upgraded to marine-grade AISI 316 stainless steel.
Every shipment is backed by a full project documentation binder including: stamped structural CAD shop drawings, factory test certificates (MTC), tempered glass SGCC/CE/AS2208 certificates, NFRC thermal performance simulations, and country-specific conformity documentation (e.g., SONCAP for Nigeria, KEBS PVoC for Kenya, CE DoP for Europe, SASO for Saudi Arabia).
Every door package contains step-by-step bilingual installation manuals, 3D exploded hardware diagrams, and QR codes linked to real-world assembly video guides. Our English-speaking fenestration engineers provide remote live video support during site rough-in, threshold leveling, and perimeter silicone waterproofing.
Submit your architectural elevations, door schedules, or tender drawings. Our senior engineering team will deliver comprehensive CAD shop drawings, structural wind-load validations, and a factory-direct quotation within 24 hours.
